We have been broken down on the trail far too many times from using inferior yokes. We do not sell cheap cast yokes. We do not sell strap style yokes. We only sell forged u-bolt style yokes that we know FROM EXPERIENCE will take the punishment hardcore off-roaders will throw at it. Drive back home instead of walk back home! End Yoke – Splined BoreFORGED 1350 series, U Bolt Style, 1.590×30 spline, 2.200 hub diameter This Forged 1350 series yoke is designed for the GM Corporate 14, 14 bolt, 10.5′ ring gear axle found in many 3/4 and 1 Ton Chevy and GM trucks from 1973 to today. Rather than the straps found in all of the other yokes available today, we designed this yoke to use u-bolts for ease of maintenance and repair. For 1998 and earlier applications, this yoke can be used directly with the existing pinion seal. For 1999 applications, the pinion face seal AAM-26060977 must be purchased and installed on the hub to match the pinion seal diameter in those axles. U-Joint Series 1350 Spline Major Diameter 1.590 Spline Count 30.000 Spline Type Involute Spline Pressure Angle 37.5 deg Ground Hub Diameter R 2.200 Length Thru Bore Q 1.630 Centerline of Joint to End of Spline S 3.550 Universal Joint Retaining Width E 3.625 Universal Joint Bearing Diameter D 1.188 Counterbore Depth 0.000 Joint Angle 22.000 Style U Bolt Compatible U-Joint Kits SPI-5-178X,SPI-5-1350X,SPI-SPL30-1X U-Bolt or Strap Assembly NDT-3-94-18X (included) Bare Yoke part number (if assembly – included) Slinger Part Number (if assembly – included) Notes FORGED Cast/Forged Forged Reviews There are no reviews yet. Be the first to review “1350 Forged, 14 Bolt Yoke, U-Bolt Style” Cancel replyYour email address will not be published. Required fields are marked *Your rating * Rate… Perfect Good Average Not that bad Very poor Your review *Name * Email * Save my name, email, and website in this browser for the next time I comment.
