24,000 BTU 23 SEER Stealth Comfort Designer Floor or Ceiling Mounted Tri Zone Heat Pump System 9 9 12

Description The Stealth Designer Series Multi Zone mini-split systems offer elite performance across a range of air handler types suitable for any application. In addition to standard wall mounted air handlers, ceiling cassette, concealed ducted and floor mounted heat console type air handlers are available. With the Designer series, different air handler types can be mixed and matched to create a custom system perfectly suited to any home or space. Additional features include continuous heating down to an outside temperature of -31 degrees and I-Feel temp sensing. 9,000 BTU Stealth Comfort Designer Floor or Ceiling Mounted Multi Zone Air Handler Stealth Designer Series Floor or Ceiling Mount Air Handlers can be surface mounted vertically or horizontally* for ultimate flexibility in placement. The wider, flatter form factor makes it a good solution when you only have vertical wall space that is close to the floor, such as in an attic room. Surface mount on the ceiling is also possible but may require a separate condensate pump to remove water. Please note: This air handler must be connected to an outdoor condenser in order to function. 12,000 BTU Stealth Comfort Designer Floor or Ceiling Mounted Multi Zone Air Handler 12,000 BTU Floor or Ceiling Mount Air Handler Stealth Designer Series Floor or Ceiling Mount Air Handlers can be surface mounted vertically or horizontally* for ultimate flexibility in placement. The wider, flatter form factor makes it a good solution when you only have vertical wall space that is close to the floor, such as in an attic room. Surface mount on the ceiling is also possible but may require a separate condensate pump to remove water. Please note: This air handler must be connected to an outdoor condenser in order to function. *Note: the 12k btu is floor mount only and cannot be located on the ceiling. Condenser Risers – 4″ x 18″ – 2 Pack Provides simple and secure mounting for small and large piping systems, ductwork runs, cable trays and smaller equipment such as condensers. Linear track offers adjustable mounting. Manufactured from exterior grade materials. Features Ideal for piping, duct runs, cable trays and condensers Weather resistant PVC Linear track holds 3/8″ hex head bolts Two 7/8″ long bolts included Weighs up to 397 Ib E Lite Equipment Pad and Risers Kit 18″ x 38″ x 3″ E Lite Condenser Pad and Risers E Lite Condenser Pad E Lite Condenser Pad is designed to provide solid support for air conditioning condensers. It’s made from sturdy polypropylene, striking a balance between lightness and stability. Its robust design ensures a level ground without the need for extra components. Key Features: Reliable Support: Abundance of ridges for stable ground support. Durable and Lightweight: Tough yet not excessively heavy, thanks to polypropylene construction. Anti-Slip: The surface prevents slipping, and rounded edges enhance safety. Simple Appearance: Gray color with size labels. Versatile Use: Suitable for condensers, pipes, ducts, cables, and more. E Lite Risers E Lite Risers complement the Condenser Pad, allowing you to adjust your setup as needed. They are constructed from weather-resistant PVC for outdoor use. Key Features: Weather Resistance: Made from tough PVC for long-lasting performance. Secure Setup: The track securely holds bolts in place. Bolts Included: Each set comes with two bolts. Strong Support: Capable of handling loads of up to 397 pounds. E Lite Condenser Pad and Risers offer reliable support without any complications. They are built to last and deliver efficient performance. Consider E Lite for your support needs – it’s a practical solution for your projects. No Return Policy All sales of this product are final and are non-refundable. Specifications 24,000 BTU 23 SEER Stealth Comfort Pinnacle Mini Split 2-3 Zone Heat Pump Condenser SKU SC-27Z-HH-M3 Refrigerant Charge Pre-charged for: 98′ Weight (in lbs) 183.000000 AHRI Certificate Number 208674945 Brand/Manufacturer Stealth Product Features Low Ambient Heating, Rebate Available Additional Information Heat Pump Additional Information Maximum Line Set Length: 82′ Additional Information Maximum System Piping: 164′ HSPF 10.5 Cooling BTU 22,000 Heating BTU 26,000 Decibel Level (dBA) Outdoor Unit: 58 dB(A) Refrigerant R410A SEER1 (Efficiency) 23-24 EER 12.5 Liquid Line 1/4″ (3) Suction Line 3/8″ (3) Electrical 208/230V 1 Phase 60Hz Phase Single Phase Max Breaker Size 35 amps Min. Breaker Size 23 amps Tonnage 2 Ton BTU/Tonnage 24,000 BTU/2 Ton Min/Max Outdoor Temp for Heating -31F – 75F Min/Max Outdoor Temp for Cooling 0F – 118F Zone Compatibility Multi Zone Height 31.1″ Width 36.2″ Depth 15.6″ Warranty 14 year compressor, 5 year parts with online registration Resources Safety Information This product and many products on our site may contain a chemical know to the state of California to cause cancer or birth defects or other reproductive harm. For more information about Proposition 65 please . 9,000 BTU Stealth Comfort Designer Floor or Ceiling Mounted Multi Zone Air Handler SKU SC-09FM-HP230 Weight (in lbs) 110.000000 Brand/Manufacturer Stealth Product Features Low Ambient Heating, WiFi Additional Information Drain: 5/8″ Cooling BTU 8,533 Heating BTU 9,556 Maximum CFM 328 CFM Decibel Level (dBA) Indoor Unit: 36-40 dB(A) Electric Heat Heat Pump Refrigerant R410A Liquid Line 1/4″ Suction Line 3/8″ Electrical 208/230V 1 Phase 60Hz BTU/Tonnage 9,000 BTU/0.75 Ton Mini Split Type Floor Mounted Zone Compatibility Multi Zone Height 27.6″ Width 48″ Depth 8.9″ Warranty 14 year compressor, 5 year parts with online registration Resources Safety Information This product and many products on our site may contain a chemical know to the state of California to cause cancer or birth defects or other reproductive harm. For more information about Proposition 65 please . 12,000 BTU Stealth Comfort Designer Floor or Ceiling Mounted Multi Zone Air Handler SKU SC-12FM-HP230 Weight (in lbs) 110.000000 Brand/Manufacturer Stealth Product Features WiFi, Low Ambient Heating Additional Information Drain: 5/8″ Cooling BTU 11,946 Heating BTU 13,140 Maximum CFM 382 CFM Decibel Level (dBA) Indoor Unit: 36-40 dB(A) Refrigerant R410A Liquid Line 1/4″ Suction Line 3/8″ Electrical 208/230V 1 Phase 60Hz BTU/Tonnage 12,000 BTU/1 Ton Mini Split Type Floor Mounted Zone Compatibility Multi Zone Height 27.5″ Width 48″ Depth 9″ Warranty 14 year compressor, 5 year parts with online registration Resources Safety Information This product and many products on our site may contain a chemical know to the state of California to cause cancer or birth defects or other reproductive harm. For more information about Proposition 65 please . Condenser Risers – 4″ x 18″ – 2 Pack SKU 87762 Weight (in lbs) 5.000000 Brand/Manufacturer Online Supply E Lite Equipment Pad and Risers Kit 18″ x 38″ x 3″ SKU 87762 / EL1838-3 Weight (in lbs) 25.000000 Brand/Manufacturer Online Supply Height 3″ Width 18″ Depth 38″ Safety Information This product and many products on our site may contain a chemical know to the state of California to cause cancer or birth defects or other reproductive harm. For more information about Proposition 65 please .
