Description Attention please!!! Please kindly read the following tips before purchasing. 1. The transaction of large machinery cannot be completed on AliExpress. 2. The express fee on AliExpress has no reference value, please ignore it. We ship by sea instead of express, please contact us to get the freight to your sea port. 3. If any problem please feel free to contact with us. Whatsapp 86 18656680921 Email [email protected] Main Features: 1. Super voice frequency heated bedways cheap cnc lathe machine.2. Hardened and grounded gears in the headstock. 3. Integrated deluxe cast iron floor stand.4. Tolerance test certificate, test flow chart included. Specification C6280&C6280V Max. swing over bed φ800mm Max. swing over cross slide φ580mm Max. swing in gap φ1046mm Distance between centers 1500/2000/3000mm Effective length of gap 250mm Width of bed 400mm Spindle nose D1-8 Spindle bore φ105mm Spindle taper ∅113(1:20) Range of spindle speed 25-1600r/min Max. travel of top slide 235mm Max. travel of cross slide 420mm Max. section of tool 25×25mm Leadscrew pitch 12mm Longitudinal feeds range 0.044-1.48mm/rev Cross feeds range 0.022-0.74mm/rev Metric threads range 0.45-120mm Inch threads range 7/16-80T.P.I. Diametrical pitches range 7/8-160D.P. Module pitches range 0.25-60M.P. Tailstock quill diameter 90mm Tailstock quill travel 230mm Tailstock quill taper MT5 Main motor power 7.5kw or 11kw(op.) Coolant pump motor 90w Overall size 3210/3710/4710x1230x1670mm Packing size 3287/4387/5287×1525×1925mm N.W 3050/3445/3820kg FAQ Q1: How is the warranty? A1: Warranty time is 13 months after BL date. Q2: Can we visit your factory before order? A2: Sure. All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking. Q3: Do you have a stock? A3: Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs. Q4: What’s the MOQ? A4: One set only. Q5: How about your quality? A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services. Q6: Do you have professional engineers? A6: Yes, we have professional engineers and designers. We can provide OEM services. Q7: Can you provide customized machines? A7: Yes, we can design and manufacture according to your specific requirements. Attachments (PDF)
