Precision and Powerful GMC1425 Double Column CNC Gantry Milling Machining Center Price in China

Description Attention please!!! Please kindly read the following tips before purchasing. 1. The transaction of large machinery cannot be completed on AliExpress. 2. The express fee on AliExpress has no reference value, please ignore it. We ship by sea instead of express, please contact us to get the freight to your sea port. 3. If any problem please feel free to contact with us. Whatsapp 86 18656680921 Email [email protected] Specification GMC1425 Worktable Worktable size (L×W) 2500×1300mm T-slots size (N×W×D) 7-22×160mm Travel X/Y/Z axis travel 2600/1400/800mm Capacity Distance from spindle nose to worktable surface 160-960mm Distance between two columns 1400mm Spindle Spindle taper BT50 Spindle power 15/18.5kw Max. spindle speed 6000rpm Spindle torque 143N·m Feed Rapid feed speed (X/Y/Z) 10/10/10m/min Ball screw (diameter lead) X/Y/Z axis ball screw 6316/5016/5016 X/Y/Z guideway type X/Y:roller linear guideways, Z:box guideway Tool magazine Tool magazine capacity 24T Max. length of tool 350mm Tool change time (T-T) 3s Positioning accuracy (GB standard) Positioning accuracy（X/Y/Z） 0.03mm Re-positioning accuracy（X/Y/Z） 0.018mm Machine dimension L×W×H 7800×5500×5000mm Machine weight Max. loading of worktable 6t N.W 22.5t Attachments (PDF)
