Description Attention please!!! Please kindly read the following tips before purchasing. 1. The transaction of large machinery cannot be completed on AliExpress. 2. The express fee on AliExpress has no reference value, please ignore it. We ship by sea instead of express, please contact us to get the freight to your sea port. 3. If any problem please feel free to contact with us. Whatsapp 86 18656680921 Email [email protected] New Design GMC1120 Heavy-Duty Accuracy Cnc Gantry Milling Machine from China Specification GMC1120 Worktable Worktable size (L×W) 2000×1000mm T-slots size (N×W×D) 7-22x125mm Travel X/Y/Z axis travel 2050/1100/600mm Capacity Distance from spindle nose to worktable surface 160-760mm Distance between two columns 1250mm Spindle Spindle taper BT50 Spindle power 15/18.5kw Max. spindle speed 7000rpm Spindle torque 143N·m Feed Rapid feed speed (X/Y/Z) 20/20/12m/min Ball screw (diameter lead) X/Y/Z axis ball screw 6320/5012/5020 X/Y/Z guideway type X/Y:roller linear guideways, Z:box guideway Tool magazine Tool magazine capacity 24T Max. length of tool 350mm Tool change time (T-T) 3s Positioning accuracy (GB standard) Positioning accuracy（X/Y/Z） 0.03mm Re-positioning accuracy（X/Y/Z） 0.018mm Machine dimension L×W×H 6800×4000×3900mm Machine weight Max. loading of worktable 4t N.W 19t Attachments (PDF)
