Description Why Choose YIHAI’s Handheld Welder? YIHAI’s Handheld Welder 1.1 The Engine for Uninterrupted Welding: The integrated water-cooling system of our unit maintains the laser source at its best operating temperature which prevents thermal throttling during extended work periods thus enabling continuous operation at 100% duty cycle in demanding high-intensity environments. 1.2The industrial power range extends from 1500W to 6000W to support all fabrication needs. 1.3 True Handheld Portability: The device enables users to access tight corners and complex geometries which robotic arms and stationary TIG stations fail to reach. 1.4 Superior Weld Quality: The process produces welds which have clean seams that are narrow and aesthetically pleasing while maintaining high tensile strength and showing minimal material distortion. 1.5 Simplified Operation: The system enables you to decrease your need for skilled welders who cost a lot because new users can produce expert-quality welds after completing basic training that lasts only a few hours. What is a Water-Cooled Handheld Laser Welder? Water-Cooled Handheld Laser Welder 2.1 Technical Definition: The system uses a handheld gun to direct high-energy density laser beams which create instant metal base and welding wire fusion into a strong bond. 2.2 The Core Innovation: Stability is the soul of laser welding. The integrated chiller system enables direct coolant flow through both the laser source and welding head which prevents the power drift that occurs in inferior systems. 2.3 The Complete Solution: A harmonized ecosystem consisting of the Fiber Laser Source, an Intelligent Chiller, and an Ergonomic Welding Gun. Technical Specifications Feature 1500W – 2000W 3000W – 4000W 6000W Max Welding Depth (SS) 3.0mm – 5.0mm 8.0mm – 10.0mm 12.0mm Cooling Power 1.5kW – 2.5kW 4.0kW – 6.0kW 9.0kW Power Supply Single Phase 220V 3-Phase 380V 3-Phase 380V Laser weight 56±5KG 56±5KG 56±5KG Gross Weight ~200kg ~280kg ~450kg Overall dimensions 1155 × 685 ×1250mm 1155 × 685 ×1250mm 1155 × 685 ×1250mm Anatomy of Reliability: Inside the YIHAI System Every component is selected not for its spec sheet alone, but for its role in a symphony of uninterrupted operation. Engineering Excellence: A Look Inside the YIHAI Welder 3.1 Industrial Fiber Laser Source: Raycus, IPG, The system operates with exceptional stability while maintaining a service life of more than 100,000 hours. 3.2 High-Efficiency Intelligent Chiller: The system operates with dual-circuit cooling which maintains power output stability through precise temperature control at ±1°C. 3.3 Ergonomic Handheld Welding Head: The welding head combines light weight construction with safety sensors and collision protection and supports both wire and gas feed systems. 3.4 Intuitive Control System: The system provides a simple touch interface which allows users to access all material and thickness settings through a single button. 3.5 Complete Core Package: The standard equipment of each unit includes an automatic wire feeder together with a dedicated gas delivery system. Water-Cooled vs. Air-Cooled The YIHAI Water-Cooled System stands as the single option which serves all needs for heavy-duty operations. Continuous Production: The operation of air-cooled units needs scheduled shutdowns because they cannot operate continuously without overheating. The system requires liquid cooling to handle its high power consumption which exceeds 3000W. Harsh Environments: The system delivers superior results when operators work in hot environments of their workshops. Laser Welding vs. Traditional Methods (TIG/MIG/Arc) 6.1 Minimal HAZ: The Heat-Affected Zone from laser welding remains small which prevents the two welding issues that TIG welding produces: warping and “burn-through”. 6.2 Speed: The system operates at speeds which reach 4x to 10x above conventional TIG welding rates thus reducing your expenses for each manufactured part. 6.3 Aesthetics: The laser process produces a “fish-scale” finish which eliminates the requirement for additional grinding or polishing operations before product shipment. 6.4 TCO Analysis: The system provides lower electricity consumption and reduced labor costs which enable a faster Return on Investment (ROI). Recus laser source Intelligent Chiller System Smart Control Platform wire feeder Versatile Application Areas The welders who work in our organization form the fundamental structure which supports various industrial sectors. Mold & Tool Repair: The process fills precise areas while protecting the entire mold surface from damage. Heavy Machinery & Shipbuilding: The process of assembly becomes faster through the replacement of bulky arc welders. Kitchenware & Hardware: The system unites stainless steel cabinets with doors through a single connection. Automotive: The company specializes in exact repair work for strong components which require high precision. The YIHAI Partnership: More Than a Machine Our products are engineered to be reliable. They are subjected to 48 hours of burn in at full power before they are dispatched. We’re the company that believes in your potential. The local presence of our business combined with our global support means that we have partners and a stock of spare parts in major industrial locations which means you will never be left waiting for the support you need. Benefits are Measurable: The numbers tell the story: lower labour costs, a reduction in expendable supplies (e.g. grinding discs), less reworking of projects and the potential to compete for higher margin projects lead to payback periods of twelve to eighteen months. Our company has a team of experienced engineers with in-depth knowledge of welding processes. They can help you achieve the best results with your project by advising on and optimising the welding parameters. Everything You Need, Delivered Laser Welding Consumables Right from the outset the Yihai package is fully functioning. Main Laser Welding Power Unit Handheld MIG Welder Gun with 10 ft Fibre optic and 20 ft Earth lift cable. Industrial High-Capacity Water Chiller Unit Digital Wire Feeder Dual-Stage Gas Regulator & Flowmeter Comprehensive Digital Manual & On-Demand Video Library Full Operator Safety Kit (ANSI-Rated Laser Glasses, Gloves) Starter Consumable Kit (Nozzles, Ceramic Sleeves, Tips) Our Service Covenant: From Inquiry to Expertise Pre-Sale Collaboration: Our no-obligation welding process audit will help you establish the reasons behind your welding operation costs. We Test Your Materials: Please send us a sample. We will process the data, document the parameters involved and return the results to you in a full report. Total Price Transparency: The price you are quoted includes all costs – shipping, duties and the cost of the machine itself. Laser Welding Package After-Sale Empowerment: The initial step in commissioning a plant or unit process involves a virtual commissioning or “walkdown”. This walkdown is a live, two-way video teleconference between the client’s team and the Beaufort Sigma engineer team. Our comprehensive training program is available on-line, and it gives our customers access to a wide range of courses. These courses are designed to cover every level of training from the basics of the product operation through to complex fault diagnosis and rectification. Direct line to our technical support team – Priority access to our technical support team via a direct phone line or other dedicated channels to quickly resolve technical problems. Warranty & Assurance: Comprehensive two-year guarantee is provided on the laser source and the main machine. The product has a comprehensive eighteen month guarantee for the entire chiller system. For extra peace of mind over the long term purchase an extended warranty. FAQ: Questions We Answer Every Day Q: What is the duration needed to train an operator? A: The machine requires 1-2 days to perform basic operations on standard materials. The process of learning parameter optimization techniques for specific use cases requires 3-5 days of training. We provide the training framework. Q: What about reflective materials like aluminum and copper? A: The systems we use include brightness and reflectivity control functions which operate successfully with these materials. The selection of specific parameters together with gas choice represents essential factors. Q: What are the ongoing costs? The main components used in this process consist of electricity and shielding gas which includes argon and nitrogen. The costs of consumable materials (nozzles and lenses) remain minimal because they do not approach the expense of MIG/TIG tips and gas cups. Q: Does the system have the ability to connect with robotic cells for future implementation? A: Absolutely. The fundamental laser source together with its cabinet section enables robotic integration which enables you to transition from manual to automated welding operations when your business expands. Q: What are the standard times which producers need to create their products before they start their delivery process? A: Standard configuration units are typically ready for shipment in 10-15 business days. The company offers express production choices to its customers.
